OIL FILTER FOR SCREW COMPRESSOR

The dust contained in the absorbed air will be remained in the air filter. To prevent the screw air compressor from being abraded or the air oil separator from being blocked, the filter element needs cleaning or replacement after having been used for 500hours. In the application environment where heavy dust exists, you need to shorten the replacement cycle. Stop the machine prior to the filter replacement. For the purpose of minimizing the stop time, a new filter or a cleaned spare filter is recommended.

1. Slightly tap both ends of the filter against a flat surface, so as to get rid of most of the heavy, dry dust.

2. Use the dry air of below 0.28Mpa to blow against the direction of air suction. The distance between the nozzle and folded paper should be at least 25mm. And use the nozzle to blow up and down along with the height.

3. After checking, you should discard the filter element if it has any holes, damage, or become thinner.
